8Appendix
8.1.1 Dimensions
P2 NON-
BYPASS
P2 BYPASS
P3 NON-
BYPASS
P3 BYPASS
P4 NON-
BYPASS
P4 BYPASS
P5 NON-
BYPASS
P5 BYPASS
A 8.86 [225.0] 9.11 [231.4] 9.57 [243.0] 9.57 [243.0] 12.69 [322.3] 12.69 [322.2] 15.13 [384.3] 15.13 [384.2]
A16.66 [169.1]-------
B 29.92 [759.9] 41.77 [1061.0] 34.33 [872.0] 43.23 [1098.0] 39.58 [1005.4] 54.38 [1381.4] 45.79 [1163.1] 59.64 [1514.9]
C 11.45 [290.9] 15.94 [405.0] 11.23 [285.2] 17.70 [449.6] 14.78 [375.5] 17.99 [457.0] 14.78 [375.4] 18.01 [457.5]
D - 1.10 [28.0] 0.59 [15.0] 0.59 [15.0] 0.59 [15.0] 0.59 [15.0] 0.59 [15.0] 0.59 [15.0]
a 5.51 [140.0] 7.87 [200.0] 7.87 [200.0] 7.87 [200.0] 10.63 [270.0] 10.63 [270.0] 12.99 [330.0] 12.99 [330.0]
b 28.80 [731.5] 41.02 [1042.0] 32.13 [816.0] 41.18 [1046.0] 37.32 [948.0] 51.89 [1318.0] 43.54 [1106.0] 57.09 [1450.0]
c 0.27 [6.8] 0.27 [6.8] 0.33 [8.5] 0.33 [8.5] 0.33 [8.5] 0.33 [8.5] 0.33 [8.5] 0.33 [8.5]
d 0.39 [10.0] 0.43 [11.0] 0.47 [12.0] 0.39 [10.0] 0.47 [12.0] 0.59 [15.0] 0.47 [12.0] 0.59 [15.0]
e 0.49 [12.5] 0.65 [16.5] 0.72 [18.4] 0.61 [15.5] 0.91 [23.0] 0.75 [19.0] 0.94 [24.0] 0.79 [20.0]
f0.27 [6.9]0.27 [6.8]------
g0.47 [12.1]0.47 [12.0]------
h0.49 [12.5]0.65 [16.5]------
j0.31 [8.0]0.31 [8.0]------
k0.32 [8.0]0.31 [8.0]------
