Sound power levels
Discharge
Measurement conditions:
Measurements taken in a room adjacent to the room containing the FWD, at the outlet of the rectangular duct (1.5 m
long) fixed to its discharge opening.
Fan Power level in dB(A), per Hz frequency band Overall power
Unit speed 125 250 500 1000 2000 4000 8000 dB(A)
1 55 50 42 37 37 31 30 46
FWD 08 2 57 54 47 40 30 38 40 50
3 58 57 50 42 32 40 43 53
1 57 51 45 42 34 33 28 48
FWD 10 2 58 54 48 45 38 39 35 51
3 60 58 50 48 40 42 39 54
1 57 51 45 42 34 33 28 48
FWD 12 2 58 54 48 45 38 39 35 51
3 60 58 50 48 40 42 39 54
1 56 62 50 48 39 38 36 56
FWD 14 2 61 66 55 53 47 46 45 60
3 63 69 58 56 50 50 49 63
1 57 63 51 49 40 39 37 57
FWD 20 2 61 66 55 53 47 46 45 60
3 63 69 58 56 50 50 49 63
Intake
Measurement conditions:
Measurements taken at the horizontal air intake.
Fan Power level in dB(A), per Hz frequency band Overall power
Unit speed 125 250 500 1000 2000 4000 8000 dB(A)
1 56 55 55 53 46 45 42 57
FWD 08 2 63 62 60 60 53 53 53 64
3 66 65 63 62 56 55 57 67
1 62 58 55 58 51 48 44 61
FWD 10 2 66 63 60 62 56 55 52 66
3 70 67 63 65 59 59 57 69
1 62 58 55 58 51 48 44 61
FWD 12 2 66 63 60 62 56 55 52 66
3 70 67 63 65 59 59 57 69
1 66 65 65 65 57 50 46 68
FWD 14 2 73 72 69 71 64 59 57 74
3 78 76 73 75 69 64 63 78
1 68 72 64 64 56 52 50 69
FWD 20 2 76 76 68 71 65 61 61 75
3 78 79 71 74 69 66 66 78
CG-SVU007D-GB
Alarms
N° Message
Reset
Type
Unit Status Description
27 Ckt2 Defrost - Unit On Defrost on Circuit 2
28 Alarm Loss of Water Flow Auto Unit Off
Loss of water ow for more than 1 sec. Pump
restarts by a manual unit mode changeover
29 Alarm Air Sensor Auto Unit Off
Faulty sensor, out of range -30..+80°C
(short circuit or open circuit)
30 Alarm Water In Sensor Auto Unit Off
Faulty sensor, out of range -30..+80°C
(short circuit or open circuit)
31 Alarm Water Out Sensor Auto Unit Off
Faulty sensor, out of range -30..+80°C
(short circuit or open circuit) (short circuit or open
circuit)
32 Alarm HT Sensor Ckt1 Auto Circuit 1 Off
Faulty sensor, out of range -30..+150°C
(short circuit or open circuit)
33 Alarm HP Sensor Ckt1 Auto Circuit 1 Off
Faulty sensor, out of range 1..46Bar
(short circuit or open circuit)
34 Alarm HT Sensor Ckt2 Auto Circuit 2 Off
Faulty sensor, out of range -30..+150°C
(short circuit or open circuit)
35 Alarm HP Sensor Ckt2 Auto Circuit 2 Off
Faulty sensor, out of range 1..46Bar
(short circuit or open circuit)
36 Alarm PHR LWT Sensor Auto Unit On
Faulty sensor, out of range -30..+80°C
(short circuit or open circuit)
37 Alarm PHR EWT Sensor Auto Unit On
Faulty sensor, out of range -30..+80°C
(short circuit or open circuit)
38
Alarm Ext. Water SP
Signal
Auto Unit On
Faulty signal, out of range 0..20mA or 4..20mA
following conguration
39
Alarm Ext. Demand Limit
SP Signal
Auto Unit On
Faulty signal, out of range 0..20mA or 4..20mA
following conguration
40 Alarm Fan1 fault Ckt1
Auto /
Manual
Circuit 1 On
(Off if only one
fan)
The 1st fan on the circuit 1 is faulty
41 Alarm Fan1 fault Ckt2
Auto /
Manual
Circuit 2 On
(Off if only one
fan)
The 1st fan on the circuit 2 is faulty
42 Alarm LP Ckt1 Fault
Auto /
Manual
Circuit 1 Off
Suction pressure on circuit 1 is below the setpoint.
Manual reset after 3 faults within 1 hour
43 Alarm LP Ckt2 Fault
Auto /
Manual
Circuit 2 Off
Suction pressure on circuit 2 is below the setpoint.
Manual reset after 3 faults within 1 hour
44 Alarm Comp. 1A Fault Manual CMP 1A Off CMP 1A is faulty
45 Alarm Comp. 1B Fault Manual CMP 1B Off CMP 1B is faulty
46 Alarm Comp. 1C Fault Manual CMP 1C Off CMP 1C is faulty
47 Alarm Comp. 2A Fault Manual CMP 2A Off CMP 2A is faulty
48 Alarm Comp. 2B Fault Manual CMP 2B Off CMP 2B is faulty
