Technical Data
FWD 08 12 20 30 45
Power supply (V/Ph/Hz) 230/1/50
Capacities
Cooling capacity on water (1) (kW) 5,2 8,3 15 18,8 30,1
Heating capacity on water (2) (kW) 6,3 11,9 18,9 20,9 38,2
Fan motor (type) 2 x direct drive centrifugal
Fan power input (3) (kW) 0,23 0,46 0,65 1,04 1,51
Current amps (3) (A) 1,1 2,2 3,1 4,7 5,5
Start-up amps (A) 3,2 5,5 9,3 14,1 16,5
Air flow
minimum (m
3
/h) 490 980 1400 1800 2700
nominal (m
3
/h) 820 1650 2300 3000 4500
maximum (m
3
/h) 980 1970 2600 3600 5400
Main coil
Water entering/leaving connections (type) ISO R7 rotating female
(Dia) 3/4" 3/4" 1 1/2" 1 1/2" 1 1/2"
Electric heater (accessory for blower only)
Electric power supply (V/Ph/Hz) 230/1/50 230/1/50 or 400/3/50 400/3/50 400/3/50 400/3/50
Heating capacity (kW) 2/4 8 10 12 12
Hot water coil (accessory for blower only)
Heating capacity (4) (kW) 6,3 12 17,4 22,4 34,5
G2 filter (filter box accessory)
Quantity 2 2 2 2 2
Dimensions ( LxWxth) (mm) 386x221x8 486x271x8 586x321x8 586*421*8 586*621*8
G4 filter (filter box accessory)
Quantity - 2 2 2 2
Dimensions ( LxWxth) (mm) - 486x264x48 586x314x48 586*414*48 586*614*48
Condensate pump (accessory) (type) Centrifugal
Water flow - lift height (l/h - mm) 24 - 500
Not available for FWD30 and FWD45
Sound level (L/M/H speed)
Sound pressure level (5) (dB(A)) 36/40/43 38/41/44 46/50/53 47/52/57 47/52/58
Sound power level (5) (dB(A)) 46/50/53 48/51/54 56/60/63 57/62/67 57/62/68
Unit dimensions
Width x Depth (mm) 890 x 600 1090 x 710 1290 x 820 1290 x 970 1290 x 1090
Height (mm) 250 300 350 450 650
Shipped unit dimensions
Width x Depth (mm) 933 x 644 1133 x 754 1333 x 864 1333 x 1008 1333*1133
Height (mm) 260 310 360 460 660
Weight (kg) 32 46 61 76 118
Colour galvanised steel
Recommended fuse size
Unit alone (aM/gI) (A) 8/16 8/16 8/16 8/25 8/25
Unit with electric heater (gI) (A) 16 (2kW),25 (4kW) 40 (230V),3*16 (400V) 3*20 3*25 3*25
(1) Conditions: Water entering/leaving temperature: 7/12 °C, Air inlet temperature 27/19°C DB/WB - Nominal air flow
(2) Conditions: Water entering/leaving temperature: 50/45 °C, Air inlet temperature 20°C DB - Nominal air flow
(3) At high speed with nominal air flow.
(4) Water entering/leaving temperature 90/70 °C, air inlet temperature 20 °C DB, Nominal air flow.
(5) A rectangular glass wool duct 1m50 long is placed on the blower.The measurement is taken in the room containing the blower unit.
Heat exchanger operating limits:
FWD:
*water temperature: max 100° C
*absolute service pressure: min 1 bar/max 11 bars
Accessories - Hot water coil:
*water temperature: min. +2° C/max. 100° C
*absolute service pressure: min 1 bar/max 11 bars
CG-SVU007D-GB
Alarms
N° Message
Reset
Type
Unit Status Description
49
Warning Comp.1A
Maintenance
Manual Unit On
Compressor running hours above the threshold
dened in unit conguration. Each compressor
start is equal to 3 running hours.
50
Warning Comp.1B
Maintenance
Manual Unit On
51
Warning Comp.1C
Maintenance
Manual Unit On
52
Warning Comp.2A
Maintenance
Manual Unit On
53
Warning Comp.2B
Maintenance
Manual Unit On
54 Alarm HT Ckt 1 Fault Manual Circuit 1 Off High Discharge Temperature Fault on Ckt1
55 Alarm HT Ckt 2 Fault Manual Circuit 2 Off High Discharge Temperature Fault on Ckt2
56
Alarm CMP Involute Press
Diff Ckt 1
Manual Circuit 1 Off
High CMP Involute Pressure Differential Fault on
Ckt1
57
Alarm CMP Involute Press
Diff Ckt 2
Manual Circuit 2 Off
High CMP Involute Pressure Differential Fault on
Ckt2
58
Alarm Low Sat Suction
Temp Ckt 1
Manual Circuit 1 Off Low Suction Saturated Temperature Fault on Ckt1
59
Alarm Low Sat Suction
Temp Ckt 2
Manual Circuit 2 Off Low Suction Saturated Temperature Fault on Ckt2
60
Alarm Low SuperHeat
Ckt1
Manual Circuit 1 Off
Low Super Heat warning on circuit 1 occurred
three times in one hour
61
Alarm Low SuperHeat
Ckt2
Manual Circuit 2 Off
Low Super Heat warning on circuit 2 occurred
three times in one hour
62
Alarm Low water
temperature
Manual Unit Off
LWT < antifreeze or INT (antifreeze-
EWT)<=10°Cxsecond
63 Alarm HP Ckt1 Fault Manual Circuit 1 Off High Pressure Cut-Out circuit 1
64 Alarm HP Ckt2 Fault Manual Circuit 2 Off High Pressure Cut-Out circuit 2
65
Alarm Ckt 1 Fault (1st
fan or all CMP)
Manual Circuit 1 Off
Simultaneous faults on compressors 1A and 1B
(1A, 1B and 1C for units #36, #39 and #45) or
Fan 1 Fault Ckt1 for units #7 to #20, #35 and
#40.
66
Alarm Ckt 2 Fault (1st
fan or all CMP)
Manual Circuit 2 Off
Simultaneous faults on compressors 2A and 2B
or Fan 1 Fault Ckt2 for units #7 to #20, #35 and
#40.
67 Alarm Unit Fault Manual Unit Off
Simultaneous faults on Ckt1 and Ckt2 on duplex
units
68 Alarms pCOe 5 ofine Auto Unit On pCOextension5 is ofine
69
Alarms pCOe 5 Analog
input 1
Auto Unit On pCOextension5 is in default on Analog input #1
70
Alarms pCOe 5 Analog
input 2
Auto Unit On pCOextension5 is in default on Analog input #2
71
Alarms pCOe 5 Analog
input 3
Auto Unit On pCOextension5 is in default on Analog input #3
72
Alarms pCOe 5 Analog
input 4
Auto Unit On pCOextension5 is in default on Analog input #4
