fully closed.
 When all outdoor units are running:
 All EXVAs are controlled according to discharge temperature.
4.6 Outdoor Fan Control
The speed of the outdoor unit fans is adjusted in steps, as shown in Table 3-4.2.
Table 3-4.2: Outdoor fan speed steps
Fan speed index
Fan speed (rpm)
8-16HP
18-22HP
24-30HP
FANA / FANB
FANA / FANB
0
0
0 / 0
0 / 0
1
120
150 / 0
120 / 0
2
150
190 / 0
150 / 0
3
170
230 / 0
170 / 0
4
190
270 / 0
190 / 0
5
210
310 / 0 (150 / 150)
210 / 0
6
230
350 / 0 (180 / 180)
230 / 0
7
250
380 / 0 (210 / 210)
250 / 0 (120 / 120)
8
270
410 / 0 (240 / 240)
270 / 0 ( 150 / 150)
9
290
280 / 280
330 / 0 (170 / 170)
10
310
320 / 320
370 / 0 (190 / 190)
11
330
360 / 360
210 / 210
12
350
400 / 400
230 / 230
13
370
440 / 440
250 / 250
14
390
480 / 480
270 / 270
15
410
520 / 520
290 / 290
16
430
560 / 560
310 / 310
17
450
600 / 600
330 / 330
18
470
640 / 640
350 / 350
19
490
680 / 680
370 / 370
20
510
720 / 720
400 / 400
21
530
750 / 750
430 / 430
22
560
780 / 780
470 / 470
23
580
800 / 800
510 / 510
24
600
840 / 840
550 / 550
25
630
880 / 880
600 / 600
26
650
910 / 880
650 / 650
27
700
910 / 910
680 / 680
28
750
940 / 910
700 / 700
29
800
940 / 940
750 / 750
30
850
980 / 940
780 / 780
31
880
980 / 980
800 / 800
32
910
1000 / 980
830 / 830
33
930
1000 / 1000
850 / 850
34
960
1020 / 1000
870 / 870
35
1000
1020 / 1020
890 / 890
36
1050
1050 / 1050
920 / 920
37
1100
1100 / 1100
950 / 950
Note:
1. For 18-22HP unit fan speed 5 to 8 and 24-30HP unit fan speed 7 to 10, when fan speed decreases, the fan speed is shown in the bracket; when fan speed
increases, the fan speed is shown without bracket.

Trane TVR Pro CO 4TVY0229H8000AA Specifications

General

Model Number	4TVY0229H8000AA
Category	Air Conditioner
Brand	Trane
Series	TVR Pro CO
Cooling Capacity	22, 900 BTU/h
Refrigerant Type	R-410A
Voltage	208/230V
Phase	1
Sound Level (Outdoor Unit)	72 dB
Operating Temperature Range (Cooling)	14°F to 115°F
SEER Rating	16 SEER
Warranty	10 years
