23
Backlite/Display
The Backlite/Display screen is used to set the backlight time-out and
contrast.
Backlite Timeout is the time (in seconds) from the last button press to the
backlight going out. The time-out can be set between zero (0) and one
hundred and twenty (120) seconds. Thirty (30) is the default setting. When
set to zero (0), the backlight will remain always on.
Contrast sets the contrast level of the LCD display. The contrast can be
set between zero (0) and twenty (20). Ten (10) is the default setting. If the
display is too light, using a higher number. If dark lines appear in the display,
use a lower number.
Adjust the Backlight
1. Press the MENU button.
2. Scroll to UserÎSettings and press the Select button.
3. Scroll to Backlite/Display and press the Select button.
4. Scroll to BackliteÎTimeout.
5. Press the plus (+) or minus (-) buttons to change the number of seconds.
ÎÎ The backlight time-out can be set between 0 and 120 seconds. Thirty (30) is the default setting. When set to Zero (0), the
backlight will remain always on.
Adjust the Contrast
1. Press the MENU button.
2. Scroll to UserÎSettings and press the Select button.
3. Scroll to Backlite/Display and press the Select button.
4. Scroll to Contrast.
5. Press the plus (+) or minus (-) buttons to change the contrast value.
ÎÎ The contrast can be set between 0 and 20. Ten (10) is the default setting.
ESM Setpoints
Energy Saving Mode (ESM) Setpoints are the setpoints used when the
EnergyÎSavingÎMode schedule is selected in the ScheduleÎMode screen.
Adjust ESM Setpoints
1. Press the MENU button.
2. Scroll to ESMÎSetpoints and press the Select button.
3. To adjust the heat setpoint, scroll to ESMÎ-ÎHeat. Press the plus (+) or
minus (-) buttons to adjust the setpoint.
4. To adjust the cool setpoint, scroll to ESMÎ-ÎCool. Press the plus (+) or
minus (-) buttons to adjust the setpoint.
Backlite/Display
Backlite Timeout 60
Contrast 10
Done
+ -
Energy Saving Mode Setpoings
ESM - Heat 65
ESM - Cool 80
Done
+ -
