IPB-99-7-EN-10-6-99 13
Performance
Data Heating Metric Units
WCC030FD00B AT 0.47 CUBIC METERS/SEC
O.D. HEATING CAPACITY IN KILOWATTS AT TOTAL POWER IN KILOWATTS AT
TEMP. INDICATED INDOOR DRY BULB TEMP. INDICATED INDOOR DRY BULB TEMP.
C. 23.3 31.7 35.8 40.0 23.3 31.7 35.8 40.0
-27.8 2.33 2.26 2.22 2.18 1.62 1.69 1.72 1.75
-25.0 2.67 2.59 2.55 2.51 1.70 1.77 1.81 1.84
-22.2 3.02 2.92 2.87 2.82 1.78 1.86 1.90 1.93
-19.4 3.34 3.25 3.19 3.14 1.86 1.94 1.98 2.02
-16.7 3.69 3.57 3.52 3.46 1.94 2.03 2.07 2.12
-13.9 4.04 3.90 3.84 3.78 2.02 2.11 2.16 2.21
-11.1 4.37 4.25 4.16 4.10 2.10 2.20 2.25 2.30
-8.3 4.72 4.57 4.51 4.42 2.18 2.29 2.34 2.39
-5.6 5.27 5.10 5.04 4.95 2.26 2.37 2.42 2.47
-2.8 5.83 5.65 5.57 5.48 2.34 2.45 2.50 2.56
0.0 6.39 6.18 6.09 5.98 2.41 2.53 2.59 2.65
2.8 6.94 6.71 6.62 6.50 2.49 2.61 2.67 2.73
5.6 7.47 7.27 7.15 7.03 2.57 2.69 2.76 2.82
8.3 8.94 8.67 8.53 8.41 2.66 2.79 2.85 2.91
11.1 9.64 9.35 9.20 9.05 2.73 2.87 2.94 3.00
13.9 10.37 10.05 9.87 9.73 2.81 2.95 3.02 3.09
16.7 11.08 10.72 10.55 10.37 2.89 3.04 3.11 3.18
19.4 11.78 11.40 11.22 11.05 2.97 3.12 3.19 3.27
22.2 12.48 12.10 11.90 11.69 3.05 3.20 3.28 3.35
CORRECTION FACTORS - OTHER AIRFLOWS
(VALUE AT 0.47 CMS TIMES CORR. FACTOR
= VALUE AT NEW AIRFLOW)
AIRFLOW 0.41 0.53
HEATING CAP. X0.98 X1.02
COMPR. KW X1.02 X0.98
VALUES AT ARI RATING CONDITIONS OF:
21&8/6 (HIGH TEMP. POINT)
21&(-8)/(-9) (LOW TEMP. POINT)
AIRFLOW = 0.47 CMS
HEATING CAP. (HIGH TEMP.) = 8.67 KILOWATTS
HEATING CAP. (LOW TEMP.) = 4.57 KILOWATTS
COMPR. POWER (HIGH TEMP.) = 2195 WATTS
COMPR. POWER (LOW TEMP.) = 1695 WATTS
COEFF. OF PERF. (HIGH TEMP.) = 3.12
COEFF. OF PERF. (LOW TEMP.) = 2.00
OUTDOOR FAN POWER = 250 WATTS
INDOOR FAN POWER = 340 WATTS
NOTE: RATED WITH 7.62 METERS OF 7/8
SUCTION AND 3/8 LIQUID LINE
WCC040FD00B AT 0.63 CUBIC METERS/SEC
O.D. HEATING CAPACITY IN KILOWATTS AT TOTAL POWER IN KILOWATTS AT
TEMP. INDICATED INDOOR DRY BULB TEMP. INDICATED INDOOR DRY BULB TEMP.
C. 23.3 31.7 35.8 40.0 23.3 31.7 35.8 40.0
-27.8 3.08 2.99 2.96 2.92 2.27 2.36 2.40 2.45
-25.0 3.55 3.43 3.40 3.34 2.35 2.45 2.49 2.54
-22.2 3.98 3.87 3.84 3.78 2.43 2.53 2.58 2.64
-19.4 4.42 4.31 4.25 4.19 2.51 2.62 2.67 2.73
-16.7 4.86 4.75 4.69 4.63 2.58 2.70 2.76 2.82
-13.9 5.33 5.19 5.13 5.07 2.66 2.79 2.85 2.91
-11.1 5.77 5.63 5.57 5.48 2.74 2.87 2.94 3.01
-8.3 6.21 6.07 5.98 5.92 2.82 2.96 3.03 3.10
-5.6 6.97 6.80 6.71 6.62 2.93 3.07 3.15 3.22
-2.8 7.74 7.56 7.44 7.35 3.04 3.19 3.26 3.34
0.0 8.50 8.29 8.17 8.06 3.14 3.30 3.38 3.46
2.8 9.26 9.02 8.91 8.79 3.25 3.42 3.50 3.58
5.6 10.02 9.76 9.64 9.49 3.36 3.53 3.62 3.70
8.3 11.87 11.54 11.40 11.22 3.48 3.66 3.75 3.84
11.1 12.80 12.45 12.28 12.13 3.59 3.78 3.87 3.96
13.9 13.74 13.36 13.18 13.01 3.70 3.89 3.99 4.09
16.7 14.68 14.30 14.09 13.89 3.81 4.01 4.11 4.21
19.4 15.62 15.21 15.00 14.77 3.92 4.13 4.23 4.33
22.2 16.55 16.11 15.88 15.68 4.03 4.24 4.35 4.46
CORRECTION FACTORS - OTHER AIRFLOWS
(VALUE AT 0.63 CMS TIMES CORR. FACTOR
= VALUE AT NEW AIRFLOW)
AIRFLOW 0.54 0.71
HEATING CAP. X0.98 X1.01
COMPR. KW X1.02 X0.98
VALUES AT ARI RATING CONDITIONS OF:
21&8/6 (HIGH TEMP. POINT)
21&(-8)/(-9) (LOW TEMP. POINT)
AIRFLOW = 0.63 CMS
HEATING CAP. (HIGH TEMP.) = 11.55 KILOWATTS
HEATING CAP. (LOW TEMP.) = 6.07 KILOWATTS
COMPR. POWER (HIGH TEMP.) = 2600 WATTS
COMPR. POWER (LOW TEMP.) = 1900 WATTS
COEFF. OF PERF. (HIGH TEMP.) = 3.18
COEFF. OF PERF. (LOW TEMP.) = 2.06
OUTDOOR FAN POWER = 500 WATTS
INDOOR FAN POWER = 560 WATTS
NOTE: RATED WITH 7.62 METERS OF 7/8
SUCTION AND 3/8 LIQUID LINE
WCC050FD00B AT 0.79 CUBIC METERS/SEC
O.D. HEATING CAPACITY IN KILOWATTS AT TOTAL POWER IN KILOWATTS AT
TEMP. INDICATED INDOOR DRY BULB TEMP. INDICATED INDOOR DRY BULB TEMP.
C. 23.3 31.7 35.8 40.0 23.3 31.7 35.8 40.0
-27.8 4.19 4.07 4.04 3.98 2.94 3.06 3.12 3.18
-25.0 4.92 4.81 4.75 4.69 3.09 3.23 3.30 3.36
-22.2 5.68 5.54 5.48 5.39 3.25 3.40 3.47 3.55
-19.4 6.42 6.27 6.18 6.09 3.41 3.57 3.65 3.73
-16.7 7.18 7.00 6.91 6.83 3.57 3.74 3.82 3.91
-13.9 7.91 7.71 7.62 7.53 3.72 3.91 4.00 4.09
-11.1 8.64 8.44 8.35 8.23 3.88 4.08 4.17 4.27
-8.3 9.41 9.17 9.05 8.94 4.04 4.25 4.35 4.45
-5.6 9.93 9.70 9.58 9.46 4.08 4.29 4.39 4.50
-2.8 10.49 10.23 10.11 9.96 4.12 4.33 4.44 4.54
0.0 11.05 10.75 10.61 10.49 4.16 4.37 4.48 4.59
2.8 11.57 11.28 11.13 10.99 4.20 4.42 4.53 4.63
5.6 12.13 11.81 11.66 11.51 4.24 4.46 4.57 4.68
8.3 16.11 15.70 15.50 15.29 4.69 4.94 5.06 5.19
11.1 17.23 16.79 16.58 16.35 4.80 5.06 5.18 5.31
13.9 18.34 17.87 17.64 17.40 4.91 5.17 5.30 5.43
16.7 19.48 18.99 18.72 18.46 5.02 5.29 5.42 5.55
19.4 20.60 20.07 19.81 19.54 5.13 5.40 5.54 5.68
22.2 21.71 21.15 20.86 20.60 5.24 5.52 5.66 5.80
CORRECTION FACTORS - OTHER AIRFLOWS
(VALUE AT 0.79 CMS TIMES CORR. FACTOR
= VALUE AT NEW AIRFLOW)
AIRFLOW 0.69 0.89
HEATING CAP. X0.99 X1.01
COMPR. KW X1.02 X0.98
VALUES AT ARI RATING CONDITIONS OF:
21&8/6 (HIGH TEMP. POINT)
21&(-8)/(-9) (LOW TEMP. POINT)
AIRFLOW = 0.79 CMS
HEATING CAP. (HIGH TEMP.) = 15.71 KILOWATTS
HEATING CAP. (LOW TEMP.) = 9.17 KILOWATTS
COMPR. POWER (HIGH TEMP.) = 3760 WATTS
COMPR. POWER (LOW TEMP.) = 3065 WATTS
COEFF. OF PERF. (HIGH TEMP.) = 3.18
COEFF. OF PERF. (LOW TEMP.) = 2.16
OUTDOOR FAN POWER = 500 WATTS
INDOOR FAN POWER = 680 WATTS
NOTE: RATED WITH 7.62 METERS OF 7/8
SUCTION AND 3/8 LIQUID LINE
