Trane WCC040 - Indoor Blower Performance Data; WCC030 FD;WCC040 FD;WCC050 FD Blower Specs

14 IPB-99-7-EN-10-6-99
Performance
Data
Indoor Blower Performances WCC030FD
Air Flow
CFM (CMH)
[2]
High Speed [1] Low Speed
Press IN.
W.G.
(PA)
PWR
Watts
BHP
Press IN.
W.G. (PA)
PWR
Watts
BHP
750 (1270) 0.58 (145) 220 0.17 0.43 (107) 218 0.17
790 (1335) 0.56 (140) 227 0.17 0.39 (97) 225 0.18
830 (1400) 0.53 (132) 234 0.18 0.34 (85) 231 0.19
880 (1490) 0.50 (125) 241 0.19 0.28 (70) 239 0.20
920 (1554) 0.47 (117) 247 0.20 0.20 (50) 247 0.21
960 (1622) 0.44 (110) 254 0.20 0.10 (25) 254 —
1000 (1690) 0.40 (100) 260 0.21 — — —
1040 (1757) 0.36 ( 90) 267 0.21 — — —
1080 (1825) 0.32 (80) 274 0.22 — — —
1130 (1910) 0.26 (65) 281 0.23 — — —
1170 (1977) 0.21 (52) 287 0.24 — — —
1210 (2045) 0.13 (32) 293 0.24 — — —
1250 (2112) 0.05 (12) 300 0.25 — — —
———————
———————
———————
———————
———————
———————
[1] Factory setting at HI speed [2] Wet coil, no filter, no heater
Indoor Blower Performances WCC040FD
Air Flow
CFM (CMH)
[3]
High Speed Low Speed [1]
Press IN.
W.G.
(PA)
PWR
Watts
BHP
Press IN.
W.G. (PA)
PWR
Watts
BHP
1000 (1690) — — — 0.69 (172) 356 0.27
1040 (1757) — — — 0.67 (167) 365 0.27
1080 (1825) — — — 0.64 (160) 373 0.28
1130 (1910) — — — 0.60 (150) 381 0.28
1170 (1977) 0.73 (183) 431 0.33 0.57 (142) 389 0.29
1210 (2045) 0.70 (175) 440 0.34 0.53 (132) 398 0.29
1250 (2112) 0.67 (167) 450 0.35 0.49 (122) 407 0.29
1290 (2180) 0.65 (162) 459 0.36 0.45 (112) 417 0.29
1330 (2247) 0.63 (157) 469 0.38 0.40 (100) 427 0.29
1380 (2332) 0.59 (147) 478 0.39 0.35 (87) 437 0.28
1420 (2400) 0.56 (140) 488 0.40 0.28 (70) 448 0.28
1460 (2467) 0.53 (132) 498 0.41 0.19 (47) 463 0.26
1500 (2535) 0.50 (125) 508 0.42 0.10 (25) 479 0.24
1540 (2602) 0.47 (117) 518 0.43 0.01 (2.5) 495 0.23
1580 (2670) 0.44 (110) 528 0.44 — — —
1630 (2755) 0.41 (102) 537 0.45 — — —
1670 (2825) 0.38 (95) 547 0.46 — — —
1710 (2890) 0.35 (87) 557 0.47 — — —
1750 (2958) [2] 0.31 (77) 567 0.48 — — —
[1] Factory setting at LO speed
[2] Water Blow Off Unit
[3] Wet coil, no filter, no heater
Indoor Blower Performances WCC050FD
Air Flow
CFM (CMH)
[2]
High Speed [1] Low Speed
Press IN.
W.G. (PA)
PWR
Watts
BHP
Press IN.
W.G. (PA)
PWR
Watts
BHP
1170 (1980) 0.73 (184) 431 0.33 0.60 (150) 414 0.29
1210 (2050) 0.70 (175) 440 0.34 0.55 (137) 423 0.29
1250 (2120) 0.67 (167) 450 0.35 0.51 (127) 432 0.29
1290 (2180) 0.65 (163) 459 0.36 0.47 (117) 442 0.28
1330 (2250) 0.63 (157) 469 0.38 0.42 (105) 451 0.28
1380 (2340) 0.59 (148) 478 0.39 0.39 (97) 460 0.27
1420 (2400) 0.56 (140) 488 0.40 0.35 (87) 469 0.27
1460 (2470) 0.53 (132) 498 0.41 0.31 (77) 479 0.27
1500 (2540) 0.51 (127) 508 0.42 0.28 (70) 488 0.26
1540 (2600) 0.48 (120) 519 0.43 0.24 (60) 497 0.25
1580 (2670) 0.44 (110) 530 0.44 0.21 (52) 506 0.25
1630 (2760) 0.40 (100) 541 0.45 0.17 (42) 516 0.24
1670 (2830) 0.37 (92) 552 0.46 0.14 (35) 525 0.23
1710 (2890) 0.33 (83) 563 0.47 0.10 (25) 534 0.23
1750 (2960) 0.28 (70) 575 0.47 0.07 (17) 544 0.23
1790 (3025) 0.24 (60) 588 0.48 — — —
1830 (3090) 0.19 (45) 601 0.49 — — —
1880 (3180) 0.15 (37) 608 0.49 — — —
1920 (3250) 0.11 (27) 620 0.50 — — —
1960 (3315) 0.07 (17) 631 0.52 — — —
[1] Factory setting at HI speed [2] Wet coil, no filter, no heater
