Trane WCC040 - General Data - English Units; Unit Ratings and Electrical Specifications

8 IPB-99-7-EN-10-6-99
General
Data English Units
MODEL
RATED VOLTS/PH/HZ
A.R.I. RATING
RATINGS (COOLING)
1
BTUH
INDOOR AIR FLOW (CFM)
POWER INPUT (kW)
EER-95 (BTU/WATT-HR.)
6
EER-82
NOISE RATING NO.
2
RATINGS (HEATING) 1
(HIGH TEMP.) BTUH - COP
POWER INPUT (kW)
(LOW TEMP.) BTUH - COP
POWER INPUT (kW)
HSPF (BTU/WATT-HR.)
6
POWER CONNS. — V/PH/HZ
MIN. BRCH. CIR. AMPACITY
3
FUSE SIZE - MAX.(AMPS)
FUSE SIZE - RECMD. (AMPS)
COMPRESSOR
NO. USED - NO. SPEEDS
VOLTS/PH/HZ
R.L. AMPS
L.R. AMPS
BRCH. CIR. SELEC. CUR. AMPS
OUTDOOR COIL — TYPE
ROWS / F.P.I.
FACE AREA (SQ. FT.)
TUBE SIZE (IN.)
REFRIGERANT CONTROL
INDOOR COIL — TYPE
ROWS / F.P.I.
FACE AREA (SQ. FT.)
TUBE SIZE (IN.)
REFRIGERANT CONTROL
DRAIN CONN. SIZE (IN.)
DUCT CONNECTIONS
OUTDOOR FAN — TYPE
NO. USED / DIA. (IN.)
TYPE DRIVE / NO. SPEEDS
CFM @ 0.0 IN. W.G.
4
NO. MOTORS - HP
MOTOR SPEED R.P.M.
VOLTS/PH/HZ
F.L. AMPS - L.R. AMPS
INDOOR FAN — TYPE
DIA. X WIDTH (IN.)
NO. USED
DRIVE / SPEEDS (NO.)
CFM VS. IN. W.G.
5
NO. MOTORS - HP
MOTOR SPEED R.P.M.
VOLTS/PH/HZ
F.L. AMPS - L.R. AMPS
FILTER — FURNISHED?
TYPE RECOMMENDED
NO. - SIZE - THICKNESS
REFRIGERANT
CHARGE (LBS. OF R-22)
DIMENSIONS
CRATED (IN.)
UNCRATED
WEIGHT
SHIPPING (LBS.) / NET (LBS.)
WCC030FD00B
380-415/3/50
31000
1000
3.12
9.50
10.90
8.0
29600 - 3.12
2.78
15600 - 2.00
2.29
380-415/3/50
10.2
15
15
CLIMATUFF
®
1 - 1
380-415/3/50
5.7
51
4.2
PLATE FIN
2 / 15
8.62
3/8 COPPER
TXV BLEED
PLATE FIN
3 / 15
3.96
3/8 COPPER
ORIFICE - .071
3/4 FEMALE NPT
SEE OUTLINE DRAWING
PROPELLER
1 / 18
DIRECT / 1
2040
1 - 1/2
900
380-415/1/50
1.7 - 3.8
CENTRIFUGAL
10 X 9
1
DIRECT / 2
SEE FAN PERFORMANCE TABLE
1 - 1/3
900
380-415/1/50
1.1 - 2.6
NO
THROWAWAY
3 - 10 x 25
8.2 LBS.
H X W X D
35-1/4 X 38 X 57
SEE OUTLINE DRAWING
406 / 366
WCC040FD00B
380-415/3/50
39600
1325
4.10
9.70
10.95
8.4
39400 - 3.18
3.66
20700 - 2.06
2.96
6.80
380-415/3/50
13.8
20
20
CLIMATUFF
®
1 -
380-415/3/50
8.0
51
7.1
PLATE FIN
2 / 15
14.0
3/8
TXV BLEED
PLATE FIN
4 / 15
5.4
3/8
ORIFICE- .082
3/4 FEMALE
SEE OUTLINE DRAWING
PROPELLER
1 / 22
DIRECT / 1
2830
1 - 1/2
900
380-415/1/50
1.7 - 3.8
CENTRIFUGAL
11.0 X 11.0
1
DIRECT / 2
SEE FAN PERFORMANCE TABLE
1 - 3/4
900
380-415/1/50
2.1 - 4.8
NO
THROWAWAY
3 - 10 x 25
13.0 LBS
H X W X D
39-3/8 X 47 X 66
SEE OUTLINE DRAWING
561 / 521
WCC050FD00B
380-415/3/50
51600
1675
5.53
9.35
11.15
8.4
53600 - 3.18
4.91
31300 - 2.16
4.21
6.80
380-415/3/50
16.3
25
25
CLIMATUFF
®
1 -
380-415/3/50
9.8
71
10.0
PLATE FIN
2 / 15
14.0
3/8
TXV BLEED
PLATE FIN
4 / 15
5.4
3/8
ORIFICE - .096
3/4 FEMALE
SEE OUTLINE DRAWING
PROPELLER
1 / 22
DIRECT / 1
2830
1 - 1/2
900
380-415/1/50
1.7 - 3.8
CENTRIFUGAL
11.0 X 11.0
1
DIRECT / 2
SEE FAN PERFORMANCE TABLE
1 - 3/4
900
380-415/1/50
2.1 - 4.8
NO
THROWAWAY
3 - 10 x 25
12.0 LBS
H X W X D
39-3/8 X 47 X 66
SEE OUTLINE DRAWING
579 / 539
NOTES:
1 RATED IN ACCORDANCE WITH A.R.I. STANDARD 210/240.
2 CALCULATED IN ACCORDANCE WITH A.R.I. STANDARD 270.
3 CALCULATED IN ACCORDANCE WITH CURRENTLY PREVAILING NATL. ELECTRIC CODE.
4 STANDARD AIR - DRY COIL - OUTDOOR
5 STANDARD AIR - WET COIL - INDOOR
6 RATED IN ACCORDANCE WITH D.O.E. TEST PROCEDURE. HSPF IS AT THE
MINIMUM DESIGN REQUIREMENT FOR REGION IV.
