Trane WCC040 - Dimensions - Unit Outline Drawing; WCC030-050 F Rear Outline Drawing

IPB-99-7-EN-10-6-99 25
1
3
/8
(35)
1
1
/8
(30)
1
/4 (6)
1
/2 (12)
3
/4
(19)
CONDENSATE DRAIN
FOR 3/4" (19) FEMALE NPT
3 (75)
5
/8
(16)
3
/4 (19)
Dimensions
WCC030-050F OUTLINE DRAWING — Rear
ALL DIMENSIONS ARE IN INCHES (MM)
From Dwg. 21D729988 Rev. 10
MODEL
CORNER WEIGHT LBS (KG)
UNIT
WEIGHT
LBS (KG)
ABC D E F G H J K LMNP
W1 W2 W3 W4
WCC030F
94
(43)
73
(33)
80
(36)
104
(47)
318
(144)
55-1/4
(1400)
36
(915)
29-3/16
(750)
18-9/16
(470)
11-1/16
(280)
6-9/16
(170)
6-13/16
(170)
17
(430)
18-13/16
(465)
24
(610)
17-1/2
(445)
10
(250)
3
(75)
4-7/16
(115)
WCC040F
126
(57)
104
(47)
127
(58)
153
(70)
486
(220)
64-5/16
(1634)
45
(1145)
33-3/8
(846)
21-1/16
(535)
15-1/16
(385)
4-15/16
(120)
9-1/8
(230)
21-15/16
(550)
24-3/4
(628)
29
(736)
20
(500)
14
(350)
3-1/2
(90)
8-5/16
(210)
WCC050F
131
(59)
108
(49)
132
(60)
159
(72)
504
(229)
24-3/4
(628)
29
(736)
