Trane WCP036F1 - Unit Dimensions and Clearances; Unit Outline Dimensions

Page 4
DIMENSIONAL DATA
4
MODEL
CORNER WEIGHT (LBS)
UNIT
WEIGHT
AB C D E F G H J K LMNP
W1 W2 W3 W4
WCP036F 110 82 88 118 398 62-7/8 36 29-3/16 18-9/16 11-1/16 6-9/16 11-1/8 17 19-1/4 27-1/2 17-1/2 10 3 8-3/4
WCP048F 149 104 117 134 504
64-3/8 45 33-1/8 21-1/16 15-1/16 4-15/16 9-1/8 21-15/16
24-1/4 28-1/2
20 14 3-1/2 8-5/1
6
WCP060F 149 104 117 134 504 24-1/4 28-1/2
WCP036-060F OUTLINE - BACK
