DIMENSIONAL DATA
4
MODEL
CORNER WEIGHT(LBS)
UNIT
WEIGHT
ABCDEFG H JKLMNP
W1 W2 W3 W4
WCY024G 79 74 74 104 331
56-1/2 36 29-3/16 18-9/16 11-1/16 6-9/16 6-13/16 17
21 25-3/8
17-1/2 10 3 4-7/16
WCY030G 82 64 86 110 342 21 24-3/8
WCY036G 110 82 88 118 398
64 36 29-1/16 18-9/16 11-1/16 6-9/16 11-1/8 17
19-1/4 27-1/2
17-1/2 10 3 8-3/4
WCY042G 110 82 88 118 398 19-1/4 27-1/2
WCY048G 149 104 117 134 504
65-1/8 45 33-1/8 21-1/16 15-1/16 4-15/16 9-1/8 21-15/16
24-1/4 28-1/2
20 14 3-1/2 8-5/16
WCY060G 126 98 121 157 502 20 28
WCY024-060G OUTLINE - BACK
