XT302C DELUXE PROGRAMMABLE HEAT-COOL THERMOSTAT
9
69-1213—1 (T8624)
Pub. No. 18-HD25D7-5
Table 5. Installer Self-Test Options.
Key to
Press
Test
Number Description
Heating Equipment Self-Test (10)
Time ▲ 10 Enter heating equipment self-test.
Temp ▲ 11 First stage heat turns on. When Installer Setup number 2 is 1, the system fan is also energized.
Temp ▲ 12 Second stage heat turns on.
Temp ▼ 11 Second stage heat turns off.
Temp ▼ 10 First stage heat turns off.
Cooling Equipment Self-Test (30)
Time ▲ 30 Enter cooling equipment self-test.
Temp ▲ 31 First stage cool and fan turn on.
Temp ▲ 32 Second stage cool turns on.
Temp ▲ 31 Second stage cool turns off.
Temp ▼ 30 First stage cool and fan turn off.
Fan Equipment Self-Test (40)
Time ▲ 40 Enter fan equipment self-test.
Temp ▲ 41 Fan turns on.
Temp ▼ 40 Fan turns off.
Comfort-R Terminals Self-Test (50)
Temp ▲ 50 Enter Comfort-R self-test.
Temp ▼ 51 Reads HH terminals. If the terminals are open and Comfort-R is enabled, display reads
% humidity. If the terminals are closed no % humidity displays.
Keyboard Operation Self-Test (60)
Time ▲ 60 7 Enter keyboard operation self-test.
Temp ▲ 60 9 Increase test number displays.
Temp ▼ 60 8 Decrease test number displays.
Day 60 11 Day test number displays.
Copy 60 12 Copy test number displays.
System 60 3 System test number displays.
Fan 60 10 Fan test number displays.
Set
Current
Day/Time
60 1 Set Current Day/Time test number displays.
Run
Program
60 15 Run Program test number displays.
Daylight
Time
60 19 Daylight Time test number displays.
Heat/ Cool
Settings
60 5 Heat/Cool Settings test number displays.
Wake 60 0 Wake test number displays.
Leave 60 14 Leave test number displays.
Return 60 16 Return test number displays.
Sleep 60 2 Sleep test number displays.
Filter 60 17 Filter test number displays.
i 60 13 Information test number displays.
Device Information Self-Test (70) - Refer to following section.
To Next Page
