Appendix B
Trapeze Mobility Point Installation Guide
Version 3.0
68
Confidential—Internal Draft—Confidential—Internal Draft—20 Sep 04
Table 9. MP Mechanical and Compliance Specifications
Specification Description
Size MP-341 and MP-352 (also applies to MP-101, MP-122,
MP-241, MP-252, and MP-262):
• Diameter: 16.76 cm (6.6 inches)
• Height: 4.69 cm (1.85 inches)
MP-52:
• Width: 22.00 cm (8.66 inches)
• Depth: 14.50 cm (5.71 inches)
• Height: 3.50 cm (1.38 inches)
Weight MP-341 and MP-352 (also applies to MP-101, MP-122,
MP-241, MP-252, and MP-262):
• Without mounting bracket: 0.35 kg (12.5 ounces)
• With mounting bracket: 0.40 kg (14 ounces)
MP-52:
• 0.50kg (17.6ounces)
Operating Temperature 0° C to +50° C (32° F to 122° F)
Storage Temperature -20° C to +70° C (-4° F to +158° F)
Humidity 10% to 95% noncondensing
Power over Ethernet
(PoE)
41 VDC to 49 VDC (46 VDC nominal)
Status indicators Health/MX and radio LEDs
(For descriptions of the LEDs, see “Status LEDs” on page 14.)
Wired network ports MP-341 and MP-352 (also applies to MP-101, MP-122,
MP-241, MP-252, and MP-262):
• Two RJ-45 ports for 10/100BASE-T Ethernet and Power
over Ethernet (PoE)
MP-52:
• One RJ-45 port for 10/100BASE-T Ethernet and Power
over Ethernet (PoE)
