PAGE 8 MEGA 960D PUMP OPERATION / MAINTENANCE MANUAL
3 START-UP
• Pump air supply pressure should be regulated.
• Open the fluid suction (IN) line valve, if necessary.
• Open the fluid discharge (OUT) line valve, if necessary.
• Start with air regulator at low pressure setting. Increase or decrease setting
to attain desired flow, up to 80 psig (4.1 bar). Minimum is 20 psig.
• Table 1: Consumption / Efficiency can be used to determine approximate air
consumption.
• Refer to Troubleshooting, Section 5, if pump fails to start.
ATTENTION: Prolonged periods of dry running (> 5 minutes) will damage critical
internal pump parts.
CAUTION: When handling potentially dangerous fluids under pressure,
the pump and its fittings should be placed in an enclosure.
3.1 HIGH TEMPERATURE OPERATION
Pump operation at temperatures above 60°C requires periodic tightening of the
tie bolt nuts. The frequency of this procedure is best established by the user.
3.2 PERFORMANCE CHARTS
Pumping capacity is a function of air supply pressure and volume, suction head,
suction line restrictions, discharge head, discharge line restriction, and fluid
specific gravity and viscosity.
Air Supply
Pressure
(PSIG)
Discharge
Fluid
Pressure
(PSIG)
Air
Used
(SCFM)
Cycles
Per
Minute
Displacement
IN
3
Per
Cycle
25
2
7.4
108
35
30
3
8.9
116
33
30
10
8.2
100
32
40
5
11.6
152
29
40
20
11.1
108
31
50
10
14.4
156
28
50
30
12.2
104
30
60
20
16.6
156
26
60
50
12.6
94
29
Table 1: Consumption / Efficiency
NOTE: Specification to be used to size regulators and control valves.
