IsoStrut remote lockout cable
Tools
• Cable cutter
• Torquewrenchwith2mmhexbit
1. Installthecableintheremotelockout.
2. Route the cable through the hole in the bottom of the
top tube just forward of the IsoStrut and out the drive
sideoftheheadtubehole.
3. Attheheadtube,routethewirethroughthecable.
4. AttheIsoStrut,slidetheferruleonthewire.
5. Guidethewirethroughtheslotinthecablestop.
6. Route the wire around the lockout spool and install
thesetscrew.Torqueto1Nm.
Drive side Non-driveside
7. Testthatthemechanismworkssatisfactorily.
8. Cut the wire to the appropriate length (20-30mm)
andcrimpanendcaponit.
