Trek 2022 E-CALIBER - Table of Contents; Safety

2022 E-Caliber Service Manual
1
Contents
Safety 1
Headset with Knock Block 2
Frame and drive system guards 3
Rear triangle and chainstay bridge 4
Main pivot 6
Derailleur hanger 7
Cabling overview 8
IsoStrut remote lockout cable 9
IsoStrut 10
Air volume spacer 11
Carriage wiper seals and bushings 14
Fazua system 19
Specications 20
Suspension 21
Safety
WARNING
Alwaystightenhardwaretothespeciedtorque.
Over-tightening hardware could deform or break the
hardwareorcomponents.Under-tighteninghardware
couldcausehardwareorcomponentstobecomeloose.
Either situation could damage the bicycle and result in
injurytotherider.
WARNING
All reused-fasteners with pre-applied threadlocker must
be cleaned with isopropyl alcohol and have new thread-
lockerappliedbeforere-assembly.Ifthreadlockerisnot
applied, the fasteners may loosen which could damage
thebicycleandresultininjurytotherider.
Copyright 2021 Trek Bicycle Corporation All Rights Reserved
