TREND IQView8 - Order Codes and Specifications; Electrical Specifications; Mechanical Specifications

IQView8 Touch Screen Display Data Sheet TA201232 Issue 2, 10-Jul-2012 15
Data Sheet IQView8
ORDER CODES
IQVIEW8/24 IQView8 including 2GB memory card.
IQVIEW8 SURFACE MOUNTING BOX Kit for mounting IQView8 on a at surface or double UK or USA pattress
box.
IQVIEW8 DRY PARTITION WALL BOX Kit for mounting IQView8 embedded in an dry partition wall.
CABLE/EJ105650 RJ11 plug to RJ11 plug with crossover to connect to IQ4, IQ3, IQ2xx, and
IQ1xx controller’s with RJ11 local supervisor port connector.
CABLE/EJ105651 RJ11 to 25 way D type male to connect to IQ1xx controller’s with RJ11 local
supervisor port connector and to a CNC.
CABLE/78-1172 25 way D type female to 5 in line socket adapter to connect to IQ1xx
controller’s with 5 in-line local supervisor port connector. Should be used in
conjunction with CABLE/EJ105651).
ACC/24VAC 230/24 Vac, 36 VA, transformer for IQView8 with surface mounting lugs,
and through earth (ground) connection.
SPECIFICATION
ELECTRICAL
CPU :Freescale iMX257
CPU speed :400 MHz
Memory :128 Mbytes DDR2
Input Power Supply :24 Vac ±15%, 50/60 Hz or 24 Vdc ±10%
Power consumption
24 Vac :20 VA max.
24 Vdc :440 mA, 10.5W
Mains failure protection :User conguration data is stored in
internal ash.
Display :800 x 480 pixel high colour (16 bit) LCD
Transmissive colour display with touch
screen.
Backlight :LED with autodim.
Sounder :Piezo electric - SPL 85 dBA @ 1 m
Relay output :Single pole changeover relay. AC
rating 60 VA (30 Vac max at 2 A, 24
Vac at 2.5 A). DC rating 60 W (40 Vdc
max at 1.5A, 24 Vdc at 2.5 A). Note that
UL rating applies up to 30 V maximum
@2A.
Ethernet port
Transmission :10/100 BASE-T autonegotiated
Distance :100 m, 109 yds to hub
RS232 port
Transmission :RS232, EIA/TIA,232E, V28
Distance :10 m
Baud rate :Settable by software to 1k2, 4k8, 9k6,
19k2, 38k4 baud (normally 9k6). Set to
match connected device.
Current loop Lan
Transmission :20 mA, two wire current loop, opto-
isolated, polarity independent receiver,
balanced transmitter.
Distance :Distance between units dependent on
baud rate and cable type (see below).
Cable
1k2
baud
4k8
baud
9k6
baud
19k2
baud
No. of
Wires
Belden 9182
1000 m
(1090
yds)
1000 m
(1090
yds)
1000 m
(1090
yds)
700 m
(765
yds)
2
Belden 9207
1000 m
(1090
yds)
1000 m
(1090
yds)
1000 m
(1090
yds)
500 m
(545
yds)
2
T
rend TP/1/1/22/
HF/200 (Belden
8761)
1000 m
(1090
yds)
1000 m
(1090
yds)
700 m
(765
yds)
350 m
(380
yds)
2
Trend TP/2/2/22/
HF/200 (Belden
8723)
1000 m
(1090
yds)
1000 m
(1090
yds)
500 m
(545
yds)
250 m
(270
yds)
4
Baud rate :Software settable to 1k2, 4k8, 9k6,
19k2 baud. Set to match other nodes
on Lan.
Indicators
System Status :LED, Red, Green, or Orange dependent
on status.
Ethernet LINK :Green LED
Ethernet RX :Yellow LED
MECHANICAL
Dimensions
IQView8 (inc bracket)
:255 mm (10.02”) x 175 mm (6.9”) x 48 mm (1.88”)
IQVIEW8 SURFACE MOUNTING BOX
244 mm (9.6”) x 203 mm (8”) x 46.5 mm (1.83”)
IQVIEW8 DRY PARTITION WALL BOX
234 mm (9.21”) x 170 mm (6.7”) x 60 mm (2.36”)
Weight
IQView8
1.07 kg, 2.36 lbs
IQVIEW8 SURFACE MOUNTING BOX
0.53 kg, 1.17 lbs
IQVIEW8 DRY PARTITION WALL BOX
0.265 kg, 0.58 lbs
Material
IQView8
Mainly PCABS FR
IQVIEW8 SURFACE MOUNTING BOX
Mainly PCABS FR
IQVIEW8 DRY PARTITION WALL BOX
Chassis 1.2 mm ROSH compliant black zinc plated mild
steel.
Connectors
Ethernet :RJ45
Current Loop Lan :4 wide 2 part connector with screw
terminals for 0.5 to 2.5 mm
2
cross
section area (20 to 14 AWG) cable.
RS232 :RJ11 (FCC68).
Input Power Supply :3 wide 2 part connector with screw
terminals for 0.5 to 2.5 mm
2
cross
section area (20 to 14 AWG) cable.
USB :Standard USB A connector.
Memory card slot :Memory card slot suitable for SD/MMC
card. Unit suppled with 2 Gbyte memory
card.
Relay output :3 wide 2 part connector with screw
terminals for 0.5 to 2.5 mm
2
cross
section area (20 to 14 AWG) cable
