IQView8 Touch Screen Display Data Sheet TA201232 Issue 2, 10-Jul-2012 13
Data Sheet IQView8
INSTALLATION
The IQView8 is designed for rear panel mounting. A rectangular
cutout needs to be made in the panel then the unit can be
inserted into the hole and xed into place using the two mounting
brackets. Use of the surface mounting or in wall mounting kit
enables the unit to be either surface or in wall mounted.
All units are UL rated as ‘UL916, listed open energy management
equipment’.
The procedure involves:
Mounting the unit
Running necessary power, communications, and relay
(optional) connections
Connecting power (do not power up), communications,
and relay wiring
Reading ‘End User Licence Agreement’
Powering up
Conguring the unit
Testing the unit’s conguration.
A full description of installing the unit is given in the IQView8
Installation Instructions (TG201232).
