TREND IQView8 - Physical Specifications and Mounting; Panel Mounting; Surface Mounting Box; Dry Partition Wall Box

2 IQView8 Touch Screen Display Data Sheet TA201232 Issue 2, 10-Jul-2012
IQView8 Data Sheet
Physical
IQView8 (Panel mounting)
230.0 mm (9.05")
255 mm (10.02")
37.7 mm
(1.48")
90 mm (3.54")
175 mm (6.9")
10 mm
(0.39")
30 mm
(1.19")
48 mm
(1.88")
239 mm (9.42")
6.5 mm
(0.26")
RS232
A
Power
connector
Ethernet
connector
RS232
connector
USB A
connector
SD Card
Slot
654
Relay
Output
Trend Lan
connector
Service
button
10 987
RX+ RX- TX+TX-
24 Vac/dc
24 Vac/dc
24 Vac/dc
IQVIEW8 SURFACE MOUNTING BOX (Surface Mounting)
244 mm (9.6")
45.5 mm
(1.8")
203 mm (8")
A
A= UK patress box
B = USA patress box
C = Alternative mounting points
D = Cable gland drill outs
22 mm Ø (0.86")
Removable cover
A
B
B
B
B
C
C
CC
D
D
D
IQVIEW8 DRY PARTITION WALL BOX (In Wall Mounting)
234 mm (9.21")
220 mm (8.66")
60 mm (2.36")
170 mm (6.7")
