TREND RD-WMB - Installation; Mounting Requirements

2 RS-WMB, RD-WMB Installation Instructions TG201349 Issue 4, 26-Aug-2015. Applies to 1.02.2.
RS-WMB, RD-WMB Installation Instructions
4
Mount Back Plate
3
Remove Main Module
2
Mounting Requirements (continued)
+45 °C
(+113 °F)
-10 °C
(+14 °F)
Operating Altitude: <2000 m (6562’)
(maximum accuracy 0 to 40 °C, 32 to 104 °F)
HO
2
0 %RH
90%RH
Use No 6 screws
Use 3.5 mm screws
Main module
Back plate
Conduit box
60 mm wall outlet box
UK pattress box
3 INSTALLATION (continued)
Do not mount on a dry lining wall box as this prevents fl ush
 t t i n g .
