TPE-3102WS Overview
TPE-3102WS
Package Contents
In addition to your switch, the package includes:
• Quick Installation Guide
• Power Cord (1.8m / 6 ft.)
• Rack mount kit
If any package contents are missing or damaged, please contact the retail store, online
retailer, or reseller/distributor from which the product was purchased.
TPE-3102WS Hardware Features
Front View
Rear View
• Power & LED indicators – Displays switch activities
• LED Mode – Switches the LED indicators between PoE mode and
Link/Activity mode.
• Reset Button – Press and hold the button 1~3 seconds and release to
reboot the device. Pressing the button more than 5 seconds will reset
the switch to factory defaults. The ports LEDs will turn off to indicate
that the reset was initiated.
• Mode Button – Press the mode button to change LED indicators to
display Link/Activity Mode, or PoE Mode.
• Ethernet Ports (1-8) – Connect either network PoE+ or non-PoE devices
at 2.5Gbps / 1Gbps / 100Mbps speeds.
• SFP Slots (9-10) – Supports optional 10Gbps or 1Gbps mini-GBIC SFP
modules for uplink or downlink connections.
