TRENDnet TEW-740APBO User Manual

© Copyright 2017 TRENDnet. All Rights Reserved.
TRENDnet User’s Guide
TEW-740APBO / TEW-740APBO2K
2
Encrypted Wireless
Support for wireless encryption of up to WPA2
Multiple SSIDs
Create up to eight additional SSIDs
Compatibility
Compatible with legacy wireless devices
Mounting Hardware
Pole and wall mount hardware included
* Effective wireless coverage may vary depending on the wireless device's output
power, antenna gain, antenna alignment, receiving sensitivity, and radio interference.
Additionally environmental factors such as weather conditions, physical obstacles, and
other considerations may affect performance. For optimal results, we recommended
consulting a professional installer for site survey, safety precautions, and proper
installation.
Product Hardware Features
Front View
Bottom View (Closed)
IPX6 Weather
Rated Housing
with built-in
directional sector
antenna

TRENDnet TEW-740APBO Specifications

General

5 GHz	No
2.4 GHz	Yes
Modulation	16-QAM, 64-QAM, BPSK, CCK, DQPSK, DSSS, OFDM, QPSK
Networking standards	IEEE 802.11b, IEEE 802.11d, IEEE 802.11e, IEEE 802.11g, IEEE 802.11h, IEEE 802.11i, IEEE 802.11n, IEEE 802.1D, IEEE 802.1Q, IEEE 802.1p, IEEE 802.1x, IEEE 802.3u
Spread spectrum method	DSSS
Ethernet LAN data rates	10, 100 Mbit/s
Maximum data transfer rate	300 Mbit/s
Placement	Pole, Wall
Certification	CE, FCC
International Protection (IP) code	IP67
USB 2.0 ports quantity	0
Ethernet LAN (RJ-45) ports	1
Security algorithms	HTTPS, SSID, WDS, WPA-PSK, WPA2, WPA2-PSK, WPA2-RADIUS
Number of SSID supported	8
Service Set Identifier (SSID) features	SSID broadcast on/off
Antenna features	Integrated antenna
Antenna gain level (max)	10 dBi
Input current	0.6 A
Output current	0.5 A
Output voltage	48 V
AC input voltage	100 - 220 V
AC input frequency	50 - 60 Hz
Power consumption (max)	22 W
Operating temperature (T-T)	-30 - 60 °C
Harmonized System (HS) code	85176990

Weight and Dimensions

Depth	54 mm
Width	125 mm
Height	218 mm
Weight	424 g
