LEDs
There are four/five LEDs on the front panel:
LEDs Description
Power
A steady Green light confirms that the storage server is
powered on.
LAN
A steady Green light confirms that the storage server
has a good connection to your network.
When it blinks, the storage server is receiving/
transmitting data from/to the network.
Mode
Off: No devices attached to the storage server.
When you are connecting a USB device to the storage
server, the LED starts blinking Green first, and then
lights a steady Green light to indicate the installation is
OK; the Red light indicates that the installation failed.
Backup
Off: No cards in the Card Reader.
Green: When you insert a memory card into one of the
slots, it lights Green steadily. When the system reads
the data from the card, it starts blinking Green.
Orange: When you backup files from Card Reader to
the system. When backup is finished, it turns off.
