4. Power over Ethernet (PoE) Installation
Note: This section is for the TV-VS1P only.
Using the TV-VS1P with a PoE switch
Power + Data (PoE)
Data
TV-VS1P TPE-80WS TEW-639GR
Power
Power
Jack
Internet
Cable/DSL
Modem
1. Connect a network cable from the Power over
Ethernet switch (e.g. TPE-80WS) to the
network port on the TV-VS1P. Then, follow the
steps in Section 3: Configure the
TV-VS1/TV-VS1P.
