FMS-2000C
LIT-12013531
27
Wiring the analog input to a room thermostat
Figure 21: Room thermostat wiring diagram
72˚F
PWR_IN (Max. 40VDC)
COM
TEMP_ADJUST
TEMP_SENSOR OUTPUT
(10K NTC TYPE 2 OR 3)
THERMOSTAT
Step Down
Isolation Transformer
