Teletext / Subtitle Decoding and display for supporting Closed Captions & Teletext
Audio CPU Core 667Mhz 32bit
Audio Standards MPEG-1 layer I & layer II, MP3
MPEG-2 layer II , Dolby Digital
MPEG-2 AAC/AAC+
Audio Transcoding DDP to DD for both SPDIF and HDMI audio
Audio Input / Output TV SCART for AL/AR OUT (Volume adjustable)
Tri-Link SCART for AL/AR IN/OUT (same with TV SCART)
AL/AR for RCA OUT
Optical Digital Audio SPDIF
Digital Audio SPDIF IEC-60958 for PCM data
Output Format IEC-61937 for Encoded Bitstream Data
Sampling Rate 32, 44.1, 48, and 96 KHz
Connectivity USB Port Host 2.0, 5V@1A
Software Upgrade and Diagnostic
Support external HDD for PVR Ready
Ethernet 10/100 Base-T
Software Upgrade USB Port USB
Front Panel Keypad 3 Keypads: Standby, CH Up / CH Down,
IR Sensor Yes
Rear Panel RF Input Connector* Terrestrial ANT IN: IEC type, Female 75 Ohm
Satellite LNB IN: F type, Female, 75 Ohm
Loop Through
Output Connector Terrestrial RF Loopthrough OUT: Terrestrial IEC type, Male, 75 Ohm
AV IN / OUT Dual SCART for TV / Triax Tri-Link
For TV SCART: OSD and volume adjustable
For Triax Tri-Link SCART: IN/Out (Same with TV SCART)
RCA 2x1 for AR / AL OUT
Digital Video & Audio Output HDMI Connector x1
USB Port 1, “A” Receptacles of USB HOST
Remote IR Input
(IR Receiver extender in) Phono Jack x 1 (To connect with Triax Tri-Link)
Power Jack 1, Detachable, (non standard)
Ethernet Port 1, RJ-45 (For future functionality)
Optical Digital Audio SPDIF TosLink Interface
External Power
Adapter Input AC 100~240 VAC, 50/60 Hz (2A adaptor , T.B.D. )
Output AC 12VDC @ 2A
Power Consumption Normal Operation: TBD, Standby Mode: Less than 1W
Others Mechanical Housing FP: type Q41
