Triax TSC 114 - Receiver Front and Rear Views

5
Introduction
Receiver (Front View)
Receiver (Rear View)
CHANNEL UP
CHANNEL DOWN
STANDBY BUTTON
1 2 3 4 5 6 7
8 9 10 11 12 13 14
9 HDMI
™
Output
10 USB: SW Upgrade and Record Function
11 Tri-Link SCART
12 TV SCART
13 IR In
14 DC Power Socket
1 RF Out
2 RF In
3 ETHERNET port - for future services
4 Audio L
5 Audio R
6 Digital SPDIF Coaxial
7 Power Switch
8 LNB In
