Triax TSC 114 Specification
Terrestrial
Tuner / Demodulator Standard DVB-T
Input Frequency* VHF/UHF Band
Channel Bandwidth* 7 MHz/8 MHz Switchable
Power for Active Antenna 5V@35mA with overload Protection through Coaxial Cable
COFDM System 2K, 8K Carrier, Hierarchical Supported
Demodulation Type QPSK, 16QAM, 64QAM, 256QAM
Guard Interval 1/32, 1/16, 1/8, 1/4 Active Symbol Duration
FEC 1/2, 2/3, 3/4, 5/6, 7/8
Satellite
Tuner / Demodulator Tuner Airoha AV2011
Input frequency 950 ~ 2150MHz
Input signal level -65dBm ~ -25dBm
Standard DVB-S / DVB-S2
Demodulator Availink AVL6211
8PSK / QPSK / BPSK
(SCPC / MCPC)
Symbol Rate 2 ~ 45MBaud for DVB-S
Inner code rate 1/2, 2/3, 3/4, 5/6, 7/8
Outer code RS (204/188)
2 ~ 45MBaud for DVB-S2
QPSK: 1/2, 3/5, 2/3, 3/4, 5/6, 8/9 & 9/10
8PSK: 3/5, 2/3, 3/4, 5/6, 8/9 & 9/10
LNB Control Support for Ku Band
22K Tone for H/L Band Selection
13/18V for polarization selection
with Overload Protection (up to 500mA)
DiSEqC 1.1 compliant
System Transport DVB Demultiplexer
Flash Memory 8Mbytes SPI NOR
System Memory 512MBits X 2 DDR2
Video CPU Core 667Mhz 32bit
Video Standards MPEG-1 ISO/IEC 11172-2
MPEG-2 MP@ML and MP@HL, ISO/IEC 13818-2
MPEG-4 AVC MP@L4 and HP@L4.1
Field / Frame Rate 60/30 Hz for NTSC or 50/25 Hz for PAL
Aspect Ratio 4:3, 16:9 & Letter Box
Video Input / Output Digital Video HDMI with HDCP supported
TV SCART with R/G/B, CVBS OUT (w/ OSD)
Tri-Link SCART with CVBS OUT (same with TV scart)
Tri-Link SCART with R/G/B, CVBS IN
Pin8, 16 for SCART control
Output Modes HD
1080p / 1080i / 720p / 576p
Output format changed by specific hot-key (software switchable)
SD
576i
