Trident 68 Owners Manual11
Trident 68 Group Metering Section
12-Segment
Bargraph Meter
Displays one of 2 sources as deter-
mined by the Monitor Return Switch
below (MON SOURCE and AUX TO
MTR). The meter is a peak responding
meter with a fast attack and slower re-
lease. It is very useful when used with
complex dynamic waveforms and able
to display sharp transient responses
and greatly assist the engineer when
it comes to avoiding distortion during
recording.
AUX MASTER LEVEL
This control adjusts the Aux bus mix
level that appears on the associated
Aux Output pins of the DSUB on the
rear panel.
NOTE: Since there are only Six Auxil-
iary sends on this console, this control
is not available on Group channel strip
7 and 8.
