At the end of the work, and before carrying out any type of
maintenance, perform the following operations:
1. Disconnect the plug (1) of the power supply cable (2) in the mains
supply socket (3) (Fig.1).
ATTENTION: You are advised to always wear protective
gloves, to avoid the risk of serious injury to your hands.
ATTENTION: To prevent damaging the power cable,
disconnect the plug from the mains socket by directly pulling
the plug and not the cable.
2. Turn the handlebar to the vertical position, press the uncoupling
lever (4) (Fig.2) and turn the handlebar to the vertical position
(Fig.3). When the handlebar is vertical, release the uncoupling
lever (4).
AT THE END OF WORK
ATTENTION: During this operation, do not rest your foot on
the appliance.
3. Tip back the machine and take the appliance to the place where it
is maintained and carry out all the procedures listed in the section
“RECOMMENDED PERIODIC MAINTENANCE” indicated in the
column “AT THE END OF THE WORK”.
4. Once the maintenance work is nished take the appliance to the
designated machine storage place.
ATTENTION: Park the machine in an enclosed place, on a at
surface; near the machine there must be no objects that could
either damage it, or be damaged through contact with it.
5. Lightly tip the machine back (Fig.4), block one of the rear wheels
and shift the control column backwards.
6. Turn the brush head into the vertical position (Fig.5).
7. Bring the rotated brush head into contact with the oor (Fig.6).
RECOMMENDED MAINTENANCE OPERATIONS
MAINTENANCE
1616
16
1
2
3 4
1 2 3
4 5 6
TYPE OF MAINTENANCE
AT THE END OF
WORK
WEEKLY
BEFORE A LONG
PERIOD WHEN
IT WILL NOT BE
USED
TRANSPORTING
Checking and cleaning the pad holder X X X
Checking and cleaning the solution tank (optional) X X X
