Careful cleaning of the pad holder guarantees better cleaning of the
oor as well as a longer brush motor life. To clean the pad holder,
proceed as follows:
1. Take the appliance to the dedicated dirty water drainage area.
ATTENTION: The place this operation is carried out should
comply with current environmental protection regulations.
2. Check that the plug (1) on the power cable (2) has been taken out
of the socket (3) of the mains supply(Fig.1), and if not, disconnect
it.
ATTENTION: You are advised to always wear protective
gloves, to avoid the risk of serious injury to your hands.
ATTENTION: To prevent damaging the power cable,
disconnect the plug from the mains socket by directly pulling
the plug and not the cable.
3. Check that the handlebar is in the vertical position, if not, press
the uncoupling lever (4) (Fig.2) and turn the handlebar to the
vertical position (Fig.3). When the handlebar is vertical, release
the uncoupling lever (4).
CHECKING AND CLEANING THE PAD HOLDER
4. Lightly tip the machine back (Fig.4), block one of the rear wheels
and shift the control column backwards.
5. Turn the brush head into the vertical position (Fig.5).
6. Bring the rotated brush head into contact with the oor (Fig.6).
7. Unscrew and remove the tightening keys (5) (Fig.7).
8. Remove the pad holder, remove the impurities in it.
9. Repeat the operations in reverse order to reassemble all the
parts.
ATTENTION: To tighten the keys correctly use a tightening
clamp.
1717
17
1
2
3 4
1 2 3
5
7
4 5 6
