Page 14
Minipak
General:
Data between [ ] is a mandatory program key stroke
sequence. Data between { } is to be supplied by the
programmer. Unit responses are shown between ( ).
Program Phone Number(s):
Press [{rrrr ☎ nnn nnnn #}](☎ ☎)
(☎ ☎ ☎= memory full)
Add Entry Code:
Press [#1{eeee}] (☎ ☎ ☎= memory full)
Delete Entry Code:
Press [#2{eeee}] (☎ ☎ ☎= already in memory)
Set Clock ( Optional ):
Press [#3{MMDDYYhhmmd}] ( ☎ ☎ )
Set Primary Relay on/off schedule:
Press [#4{hhmm hhmm d d}] (☎ ☎) –start and stop
time, FROM day, and TO day.
Set Secondary Relay on/off schedule ( Optional ):
Press [#5{hhmm hhmm d d}] (☎ ☎) –start and stop
time, FROM day, and TO day.
Set Tamper Code:
Press [#6{rrrr] (☎☎☎= error)
Set Program Code:
Press [#7{pppp}](☎ ☎)
Set Site ID Code:
Press [#8{iiii}](☎ ☎)
Erase Mode:
Press [#✽{t}], (where 0= all data, 1= Entry Codes,
2= Phone Numbers, 3= Defaults, 4=Clean
Memory)
Exit Program Mode:
Press [##]
Verify programming:
[✽0] Verify Setup Parameters (ssssss ☎)
[✽1] Verify unit capacity (cccc ☎)
[✽2{rrrr}] Verify phone number for Resident Code
rrrr (☎ ☎ ☎ = none listed)
[✽3] Verify Clock (MM-DD-YY-hh-mm-d,
☎☎☎ = none installed)
[✽4] Verify Relay One Schedule (hhmm hhmm
d d #, ☎☎☎= not set)
[✽5} Verify Secondary relay schedule
[✽6] Verify Tamper Code (rrrr ☎) (☎☎☎ = not
set)
[✽7] Verify Program Code (pppp )
[✽8] Verify Site ID Code (iiii ☎). (☎☎☎= not
set)
[✽9] List all entry Codes. Press {✽} to continue,
{##} to stop.
[✽✽] List all Phone Numbers. Press {✽} to
continue, {##} to stop.
[✽#] List Audit Data. Press {✽} to continue.
Press {##} to stop.
Remote Operation:
When the unit is called and auto-answers, press [X] to:
[0] Echo Tone Test (Press {#} to stop.)
[1] Memory Test (☎= good, ☎☎= bad)
[2] Send Tone Sequence (1 - 9, *, #)
[3] Latch Primary Relay (☎☎= feature
enabled).
Latch Primary Relay (☎☎☎= error, not
enabled)
[4] Unlatch Primary Relay (☎☎ = feature
enabled).
Unlatch Primary Relay (☎☎☎ = error, not
enabled)
[5] Latch Secondary Relay
[6] Unlatch Secondary relay
[7] Force Unit to hang up.
[8] Extend time-out to 3 minutes (30 sec.
Default)
[9] Toggle Sound (☎= on, ☎☎= off)
[✽{pppp}]Enter Program Mode (☎☎= accepted)
[#] Send Site ID Code (iiii, ☎☎☎= error, not
set)
Note: Warning tone occurs 10 seconds before auto
hang up.
