Trigon Electronics Minipak - Wiring Diagram; Relay and Cable Specifications

Page 5
Minipak
Figure 3
WIRING DIAGRAMWIRING DIAGRAM
WIRING DIAGRAMWIRING DIAGRAM
WIRING DIAGRAM
Microprocessor
Memory
12VAC/DC
NO NC
C
0-250' 18AWG; Shielded
250 to 500' 16AWG; Shielded
500+' 14AWG; Shielded
Input Cable Size
Door Strike
Connections
Voice Grade 24 to 48V
22AWG; Shielded or Twisted
up to 2400'
Telephone Cable
Telco
Ground
Ea r
Mouth
Mic
Spkr
Out
RTS
In
HOOK
DSR COM
PG
Microphone
Adjustment
Speaker
Volume
5 AMP
Prim ary
Rel a y
5 AMP
Relay
NO
C
Relay #2
Second Relay is Optional
on MGII, 100B, Minipak,
T.A.C. 500,1000,1500
Second Relay is Standard
on HF-2, HS-2, MGIID
100BD, MP4000
Plus
In
Ground
Po s t al
HEAT ER
Play
Button
Re cor d
But ton
W1
W3
W4
relay 2
