ELECTRICAL INSTALLATION
The electrical installation of the equipment should only be carried out by trained
personnel.
The ozone generator and dryer should be fitted with mains plugs in accordance with
the electrical safety instructions.
The mains socket into which the units are to be connected should be of the wall
mounted SWITCHED mains outlet type. The socket must be earthed.
The mains outlet socket can take its electrical feed from various sources, depending
on the method of control.
The injector booster pump should be electrically installed in line with manufacturers
recommendations and should be interlocked with the main circulation pump.
T2 ozone systems require a single outlet switched wall socket.
T4 ozone system requires a double outlet switched wall socket.
T8 ozone system requires a triple outlet switched wall socket.
The number of outlets above do not accommodate the injector booster pump supply
as this would normally be incorporated in the main filtration control panel or from a
separate pump starter unit.
NOTE: UNDER NO CIRCUMSTANCES SHOULD THE GENERATOR OR THE AI
R
DRYER BE HARD WIRED DIRECTLY TO A POWER SUPPLY. IF THIS IS DONE,
THE WARRANTY OF THE UNITS ARE IMMEDIATELY INVALID.
NOTE: UNDER NO CIRCUMSTANCES SHOULD THE GENERATOR OR THE AI
R
DRYER BE WIRED DIRECTLY INTO A FILTRATION CONTROL PANEL O
R
SIMILAR – THEY MUST BE WIRED AS INSTRUCTED ABOVE.
The reason for the above is to ensure that the units can be easily removed either fo
r
winter storage or servicing.
MANUAL CONTROL
If the ozone generator is to be manually controlled, the feed to the mains socket
should be directly from the main filtration control panel and interlocked with the
main circulating pump starter to ensure that the ozone system stops if the main
circulation system stops.
The switch on the mains outlet socket can then be used to stop and start the
ozone system manually as long as the circulating system is operational.
TIME CLOCK CONTROL
If the ozone system is to operate under time clock control together with othe
r
items of equipment, then the ozone system and booster pump should be fed from
the master control panel controlling all other equipment, again via a switched wall
socket into which the ozone generator (and air dryer) are plugged.
