ELECTRICAL INFORMATION
SYMBOLS:
The lightning flash with arrowhead symbol is to alert the user to
the presence of uninsulated “dangerous voltage” within the
product enclosure that may be of sufficient magnitude to
constitute risk of electric shock to persons.
The warning label is to instruct service personnel to disconnec
the mains supply before removing the front cover.
CAUTION: To reduce the risk of fire or electric shock, do not expose this
unit to excessive temperatures, rain or moisture.
Always disconnect this unit from the supply when not in use fo
lengthy periods.
IMPORTANT: Servicing should only be done by qualified personnel. No user
serviceable parts inside.
MAINS OPERATION:
The wires in the lead are coloured in accordance with the
following wiring codes:
BROWN…………………LIVE
BLUE…………………….NEUTRAL
YELLOW/GREEN………EARTH
The wires in the mains lead must be connected to the terminals
in the plug as follows:
BROWN WIRE…………L OR RED
BLUE WIRE……………N OR BLACK
YELLOW/GREEN……..E OR EARTH
The plug should be fitted with a 3 amp fuse
NOTE: THIS UNIT MUST BE EARTHED.
INTERNAL FUSES:
The following fuses are fitted within the equipment:
OZONE GENERATOR
220 – 240V-2 No. 1A TYPE (T) – 20mm
110 – 120V-2 No. 2A TYPE (T) – 20mm
AIR DRYER
220 – 240V No. 1.6A TYPE (T) – 20mm
110 – 120V No. 3A TYPE (T) – 20mm
