CCTV TESTER User Manual
1
1. Safety information
◆ The tester is intended for use in compliance with the local rules for electrical testers.
◆ To prevent the functional failure, the product should not come in contact with water.
◆ The exposed part of the tester should not be exposed to any liquids.
◆ During transportation and use, avoid vibration of the tester.
◆Do not leave the tester unattended while charging. If the battery becomes overheated, the tester should be immediately removed from the
electrical source. The tester should not be charged over 6 hours.
◆ Do not use the tester in high humidity conditions. Once the tester becomes damp, power off immediately.
◆ The tester should not be used in an environment with the flammable gas.
◆ Do not disassemble the instrument. There are no user replaceable parts inside.
◆ The instrument should not be used in an environment with strong electromagnetic interference.
◆ Do not touch the tester with wet hands.
◆ Do not use detergent to clean the unit. A dry cloth is recommended. If the dirt is not easy to remove, a damp cloth with water can be used.
2. IP Camera Tester Introduction
2.1 General
The 5-inch IPS touch screen IP camera tester is designed for maintenance and installation of IP cameras, analog cameras, TVI, CVI, AHD,
SDI/EX-SDI cameras, as well as testing 4K H.264 /4K H.265 camera by mainstream. The 1920x1080 resolution enables it to display a high
resolution image from the camera. The meter supports many ONVIF and analog PTZ controls. The combination of touch screen and touch
control keys make the IP camera tester very user- friendly.
2.2 Packing list
1) Tester
2) Adaptor DC12V 1A
3) Network cable tester
4) Lithium ion battery
5) BNC cable
6) RS485 cable
7) RJ45-BNC converter (Only for optional function cable tracer)
8) DC12V Power cable
9) Audio cable
10) Safety cord
11) Wrist belt
12) Tool bag
13) Manual
