CCTV TESTER User Manual
19
6.8 HDMI out
The built in HDMI output port can output live video from an analog or IP camera, recorded files, media files and images to HDTV
monitors. Connect an HDMI cable from the IP tester to an HDTV monitor at any time. It supports up to 3840x2160P 30FPS resolution.
7. Specifications
7.1 General Specifications
8150 Camview5 Security Camera Tester
New 5-inch IPS touch screen cctv tester, 1920*1080 resolution
10/100/1000M auto adjust, RJ45
Built in WIFI, speeds150M, display wireless camera image
New hardware decoding, 4K H.265/H.264 camera image
display by mainstream testing
Auto-scan the whole network segment camera IP
Search camera quickly, auto log in and display image from the
camera, activate Hikvision camera
Batch activate Hikvision camera, display image from the
camera, modify channel, batch modify IP, username and
password parameters etc.
Batch activate Dahua camera, batch modify IP, modify
channel, username and password parameters etc.
ONVIF, ONVIF PTZ, Dahua IPC-HFW2100P, Hikvision
DS-2CD864-E13, Samsung SNZ-5200, Tiandy TD-NC9200S2,
Kodak IPC120L, Honeywell HICC-2300T, RTSP Viewer
Automatically recognize type and resolution of TVI/CVI/AHD
camera and display image. Support coaxial PTZ and call OSD
menu
HD-SDI/EX-SDI
camera test
*(Optional)
1 channel SDI in（BNC interface), resolution support upto
8MP: 720p 60fps / 1080p 60fps /1080i 60fps, EX-SDI:
2560x1440P /25/30FPS, 3840 x 2160P 25/30 FPS
1 channel CVI input（BNC interface, resolution support 8MP
CVI camera test,
3840 x 2160P 12.5/15 FPS, 2880x1920P 20FPS,
2592x1944P 20FPS, 2560x1440p 25/30fps,
1920x1080p 25/30fps, 1280x720p 25/30/50/60fps,
UTC control and call OSD menu
1 channel TVI input（BNC interface ), resolution support 8MP
TVI camera test,
3840 x 2160P 12.5/15 FPS, 2592x1944p12.5/20fps,
2688x1520p 15fps, 2560x1440P 18/25/30fps,
2048x1536p 18/25/30fps, 1920x1080p 25/30fps,
