Triton 2000 - Parts Identification; Main Components; Fasteners and Hardware

Page 2
PARTS LIST
k. Saw Locators (4)
d. 8mm Washer (20)
m. M6 x 40mm Philips-
head Screws (4)
n. M6 Flange Nuts (4)
a. Leg Locking Pin (4)
b. M8 x 16 Bolt (4)
c. M8 Flange Nut (4)
e. M8 Nyloc Nut (8)
f.
M8 x 50 Bolt (8)
s. Tube Spanner
q. Trigger Strap
u. Scale
Pointer Labels (1)
r. Fence Hanger (2)
g. Push-stick
hanger (2)
p. Angled foot (4)
h. M5 Nyloc Nut (3)
j. M5 x 25 Screw (1)
o. Alignment Cams for Triton Saw
(2 sets packed in separate bag)
A Table (1)
C Rear End Panel (1)
D Legs (4)
E Bearing Channels (2)
F Base Channels (2)
G Protractor (Mitre gauge) (1)
H Crosscut
Fence (1)
I Rip Fence (1)
J Overhead Guard &
Guard Support (1)
K Side Guard (2 parts)
L Slide Chassis (1)
M Guided
Push-stick &
Side Pressure
Finger Kit (1)
N Rip Fence Bevel Guides (3 parts)
MAIN FASTENER BAG
Router Table
Series 2000
Fitting Kit
B Front End Panel (1)
t. Router Table
Fitting Kit
l. Clamping
Knobs (4)
Reverse from packed
position before using
!
SAW CLAMPING HARDWARE
(SEPARATE BAG)
i. M5 x 8 Screw (2)
N Rip Fence Bevel Guides (2 parts)
