Triton AS2000 SR - Main Components

Power Shower
6
7. PCB / power supply
8. Setting ring
9. Temperature control valve
10. Solenoid outlet
11. Cover connector
Cover outline
MAIN COMPONENTS
1. Cover screw fixing
2. Motor retaining bracket
3. Wall fixing holes
4. Pipe inlets – swing
(contains single check valves)
5. Filter cover
6. Pump
Fig.1
4
5
2
6
7
`
1
8
3
3
3
10
3
1
9
11
