Triton T80Z User Manual

23
SPARE PARTS
SPARE PARTS
Ref. Description Part No. Model
1. Inlet Filter Assembly ...................P82800843
2. Start/stop switch ........................P81901342
3. Can & Element Assembly ...........83314790 (7.5kW)
83314800 (8.5kW)
83314810 (9.5kW)
83314820 (10.5kW)
83314830 (8.5kW ECO)
4. Switch carriage ..........................P22611001
5. Pressure Switch ..........................P22611003
6. Trimplate ...................................7054303 (white)
7054304 (black)
7. Terminal block & loom ..............S82201190 (white - 7.5kW, 8.5kW, 9.5kW, ECO versions)
S82201220 (white - 10.5kW version)
S82201220 (chrome - all kW versions)
8. Outlet pipe & PRD .....................S85000260
9. Micro switch (set of 2) ...............83314900
10. Thermal Cut-Out (TCO) .............22012340
11. Stabilising Valve .........................P22640800
12. Solenoid valve ...........................P22610801
13. Pipe trims (top left) ....................7054305 (white)
7054306 (black)
14. Pipe trims (top right) .................7054307 (white)
7054308 (black)
15. Pressure Relief Device (PRD) .......82800450
16. Cover Assembly .........................P80000003 (white)
P80000004 (chrome)
..................................................P80000005 (ECO)
- Neon Assembly ..........................P22610903 (not illustrated)

Triton T80Z Specifications

General

Type	Electric Shower
Finish	White
Start/Stop Button	Yes
Cable Entry Points	Bottom
Power Ratings	8.5 kW
