3
Fig.2
DIMENSIONS & ENTRY POINTS
2
check list
SECTION
Fig.1
225mm 104mm
ENTRY POINTS
DIMENSIONS
WATER
Left: Bottom, Back, Top & Side.
Right: Bottom, Back, Top & Side.
CABLE
Left: Bottom, Back & Top.
Right: Bottom, Back & Top.
= Back
= Back
= Others
= Others
334mm
PLEASE NOTE: Deviation from the
approved entry points will invalidate
product specifications and warranty.
