Triton TRA001 Operating And Safety Instructions

Thank you for purchasing this TRITON tool. This manual contains information necessary for safe and effective operation of
this product. This product has unique features and, even if you are familiar with similar products, it is necessary to read
this manual carefully to ensure you fully understand the instructions. Ensure all users of the tool read and fully
understand this manual.
2
GB
SPECIFICATIONS
CONTENTS
Specifications 2
Product Overview 3
Symbols 4
Safety Instructions 4
Functions 6
Hand-held Operation 8
Table-mounted Operation 9
Maintenance 9
Troubleshooting 10
Warranty 11
Declaration of conformity
Contents / Specifications
Model number: TRA001
Voltage: EU - 220V – 240V AC, 50Hz
SA - 220V – 240V AC, 50Hz
AU - 220V – 240V AC, 50Hz
JP - 100V AC, 50/60Hz
USA - 120V AC, 60Hz
Input power: 2400W / 3-
1
⁄4hp
No load speed: 8,000 to 21,000rpm variable
Collets: EU -
1
⁄2" & 12mm
SA -
1
⁄2" &
1
⁄4"
AU -
1
⁄2" &
1
⁄4"
JP -
1
⁄2" & 12mm
USA -
1
⁄2" &
1
⁄4"
Plunge adjustment: 1) Free
2) Height winder
3) Micro winder
Plunge Range: 0 – 68mm / 0 – 2-
21
⁄32"
Insulation class:
Net weight: 6kg / 13.2lbs
Sound and vibration information:
Sound pressure L
PA
: 85.5dB(A)
Sound power L
WA
: 96.5dB(A)
Uncertainty K: 3dB
Weighted Vibration a
h
: 4.795m/s
2
Uncertainty K: 1.5m/s
2
As part of our ongoing product development, specifications of Triton products may alter without notice.
The sound intensity level for the operator may exceed 85dB(A) and sound protection measures are necessary.
330165_Z1MANPRO1(with Japanese).indd 2 21/07/2014 09:48

Triton TRA001 Specifications

General

Power	1400W
No Load Speed	8000 - 21000 RPM
Voltage	230 V
Power Source	Corded Electric
Motor Power	1400W
Dust Extraction	Yes
Variable Speed	Yes
Soft Start	Yes
Collet Size	1/2" & 1/4"
