Triton TRA001 Operating And Safety Instructions

3
GB
PRODUCT OVERVIEW
1. Speed Controller
2. Brush Cap
3. Power Switch
4. Retracting Power Switch Cover
5. Motor
6. Depth Stop Lock Knob
7. Side Air Vents
8. Collet Shaft
9. Turret Stops
10. Plunge Lock Lever
11. Plunge Spring Access Cap
12. Micro Winder
13. Plunge Mode Selector Button
14. Winder Handle Clutch Ring
15. Automatic Spindle Lock
16. Dust Extraction Port
17. Safety Guards
18. Baseplate Mounting Knobs
19. Fence
20. Collet (see specification table for sizes)
21. Spanner
22. Extended Baseplate
23. Pivot Mount
24. Table Height Winder
25. Table Height Winder Connection Point
Know your product
1
3
4
6
8
18
12
11
5
7
17
21
22
2
9
10
13
14
15
16
20
23
19
24
25
330165_Z1MANPRO1(with Japanese).indd 3 21/07/2014 09:48

Triton TRA001 Specifications

General

Power	1400W
No Load Speed	8000 - 21000 RPM
Voltage	230 V
Power Source	Corded Electric
Motor Power	1400W
Dust Extraction	Yes
Variable Speed	Yes
Soft Start	Yes
Collet Size	1/2" & 1/4"
