PARTS IDENTIFICATION
1. Headlight
2. Front indicator
3. Electrical accessory socket
4. Fuel tank and fuel filler cap
5. Rider’s heated seat switch (if fitted)
6. Battery and fuse boxes
7. Passenger’s heated seat switch
(if fitted)
8. USB Socket
9. Electrical accessory socket (if fitted)
10. Rear indicator
11. Rear brake caliper
12. Rear brake disc
13. Centre stand (if fitted)
14. Rear suspension damping adjuster
(Explorer XR and Explorer XC
models only)
15. Side stand
16. Gear-change pedal
17. Coolant expansion tank
18. Radiator cowl
19. Front brake caliper
20. Front brake disc
1 2 3 4 5 6 7 9 10
20 19 18 17 16 15 13 12 11
8
14
