Triumph Explorer User Manual

General Information
95
Rider's Seat
1. Rider’s seat
To remove the rider’s seat, remove the
passenger seat (see page
94).
Grasp the rider’s seat on either side, and
slide it rearwards and upwards. If
equipped with heated seats, disconnect
the heated seat’s electrical connector
for complete removal from the
motorcycle.
To refit the seat, reconnect the heated
seat’s electrical connector (if equipped).
Engage the seat's front rail into the
bracket at the rear of the fuel tank and
lower the rear rail into the rear brackets.
Push down firmly on the rear of the
seat. Refit the passenger seat (see
page
94).
1
Warning
The rider’s seat is only correctly
retained and supported once the
passenger seat is correctly fitted.
Never ride the motorcycle with the
passenger seat detached or removed,
as the front seat will not be secured
and may move.
A loose or detached seat could cause
loss of motorcycle control and an
accident.

Triumph Explorer Specifications

General

Engine Type	Liquid-cooled, 12 valve, DOHC, in-line 3-cylinder
Engine Capacity	1215 cc
Transmission	6-speed
Fuel System	Multipoint sequential electronic fuel injection
Frame	Tubular steel trellis frame
Fuel Tank Capacity	20 liters
Seat Height	840 mm
Brakes Front	Twin 305mm floating discs, 4-piston radial calipers
Brakes Rear	Single 282 mm disc, 2-piston caliper, switchable ABS
Tires Front	120/70 R19
Tires Rear	170/60 R17
Max Torque	90 lb-ft @ 6400 rpm
Wheelbase	1535 mm
