Parts Identification
Parts Identification -Thruxton
1. Front turn signal
2. Headlight
3. Brake/Tail light
4. Oil cooler
5. Rear turn signal
6. Side stand
7. Gearshift pedal
8. Front brake disc
9. Front brake caliper
10 . F u e l t a n k
11. Fuel filler cap
12.Battery
13.Rear brake disc
14.Rear brake caliper
15.Clutch cable
16.Choke control
i
1 2 11 10 16
6 7 14 1315498
12 3 5
