Triumph Scrambler - All Models Parts Identification

20
Parts Identification
Parts Identification - All Models
1. C l u t c h l e v e r
2. Headlight dimmer switch
3. Turn signal switch
4. Horn button
5. Ignition switch
6. Speedometer
7. Warning lights
8. Front brake fluid reservoir
9. Front brake lever
10.Engine stop switch
11. Tachometer (if fitted)
12.Starter button
13.Steering lock
14.Passing switch (Thruxton and
Scrambler only)
67
123 8
13541210
9
14
1176
See Below
