Triumph Street Triple RS 2022 User Manual

HOW TO RIDE THE MOTORCYCLE
122
Braking
cjxh
1
1. Front brake lever
1
1. Rear brake pedal
Warning
WHEN BRAKING, OBSERVE THE
FOLLOWING:
- Close the throttle completely, leaving
the clutch engaged to allow the
engine to help slow down the
motorcycle.
- Shift down one gear at a time such
that the transmission is in first gear
when the motorcycle comes to a
complete stop.
- When stopping, always apply both
brakes at the same time. Normally the
front brake should be applied a little
more than the rear.
- Shift down or fully disengage the
clutch as necessary to keep the
engine from stalling.
- Never lock the brakes, as this may
cause loss of control of the motorcycle
and an accident.
Warning
For emergency braking, disregard
down shifting, and concentrate on
applying the front and rear brakes as
hard as possible without skidding.
Riders should practice emergency
braking in a traffic-free area.
Triumph strongly recommends that all
riders take a course of instruction,
which includes advice on safe brake
operation. Incorrect brake technique
could result in loss of control and an
accident.

Triumph Street Triple RS 2022 Specifications

General

Engine Type	Liquid-cooled, 12 valve, DOHC, inline 3-cylinder
Displacement	765 cc
Transmission	6-speed
Front Tyre	120/70 ZR17
Rear Tyre	180/55 ZR17
Power	128 hp (95.6 kW) @ 12, 000 rpm
Torque	80 Nm @ 9, 500 rpm
Fuel Capacity	17.4 litres (4.6 US gal)
Dry Weight	166 kg
Wet Weight	189 kg
Front Suspension	Showa 41 mm upside down
Rear Suspension	Ohlins STX40 piggyback reservoir monoshock, adjustable compression and rebound damping and preload adjustment
Front Brakes	Twin 310 mm floating discs, Brembo 4-piston radial monobloc calipers
Rear Brakes	Single 220 mm disc, Brembo single piston caliper
Frame	Aluminium beam twin spar
