Triumph Street Triple RS 2022 User Manual

MAINTENANCE
171
Rear Suspension Spring Preload
Adjustment
Street Triple S (40.2cuin (660cc))
The spring preload adjuster is located at
the top of the rear suspension unit.
cjxi
3
1
2
1. Peg
2. Position 1 (minimum adjustment)
3. Adjustment tool
To change the spring preload setting:
▼ Insert the adjustment tool supplied
in the tool kit into the slot in the
adjuster ring.
▼ Turn the adjuster ring
counterclockwise to increase spring
preload, and clockwise to decrease
spring preload.
▼ When delivered from the factory, the
spring preload adjuster will be set to
the Solo Riding position as shown in
the suggested suspension settings
table.
▼ Adjuster settings are counted from
position one with position one being
with the adjuster turned fully
clockwise. Position one gives the
minimum amount of spring preload.
Rear Suspension Rebound Damping
Adjustment
Street Triple R
The rebound damping adjuster is
located at the bottom of the rear
suspension unit on the left hand side of
the motorcycle.
cjye
1
1. Slotted adjuster
To change the rebound damping setting:
▼ Rotate the slotted adjuster clockwise
to increase rebound damping and
counter-clockwise to decrease.

Triumph Street Triple RS 2022 Specifications

General

Engine Type	Liquid-cooled, 12 valve, DOHC, inline 3-cylinder
Displacement	765 cc
Transmission	6-speed
Front Tyre	120/70 ZR17
Rear Tyre	180/55 ZR17
Power	128 hp (95.6 kW) @ 12, 000 rpm
Torque	80 Nm @ 9, 500 rpm
Fuel Capacity	17.4 litres (4.6 US gal)
Dry Weight	166 kg
Wet Weight	189 kg
Front Suspension	Showa 41 mm upside down
Rear Suspension	Ohlins STX40 piggyback reservoir monoshock, adjustable compression and rebound damping and preload adjustment
Front Brakes	Twin 310 mm floating discs, Brembo 4-piston radial monobloc calipers
Rear Brakes	Single 220 mm disc, Brembo single piston caliper
Frame	Aluminium beam twin spar
