Triumph Street Triple RS 2022 User Manual

GENERAL INFORMATION
46
Odometer and Speedometer
The odometer shows the total distance
that the motorcycle has traveled.
The speedometer indicates the road
speed of the motorcycle.
3
0 0
2 2
4 4
6 6
8 8
10 10
12 12
52
F E C H
21.5 10:55
AM
C
o
x1000rpm
SET 100
9
ABS
+
MPH
SERVICE
Recommended by
03/2020
or in
460 miles
ODO: 0001234 mi
1
2
1. Odometer
2. Speedometer
Tachometer
Caution
Never allow engine speed to enter the
red zone as severe engine damage
may result.
The tachometer shows the engine
speed in revolutions per minute - rpm
(r/min). At the end of the tachometer
range there is the red zone. Engine
speeds in the red zone are above
maximum recommended engine speed
and are also above the range for best
performance.
3
0 0
2 2
4 4
6 6
8 8
10 10
12 12
6400
52
F E C H
21.5 10:55
AM
C
o
x1000rpm
RPM
SET 100
9
ABS
+
MPH
TACHOMETER
1
2
1. Engine speed (rpm) shown in a numerical
format
2. Engine speed (rpm) shown in a graph
format

Triumph Street Triple RS 2022 Specifications

General

Engine Type	Liquid-cooled, 12 valve, DOHC, inline 3-cylinder
Displacement	765 cc
Transmission	6-speed
Front Tyre	120/70 ZR17
Rear Tyre	180/55 ZR17
Power	128 hp (95.6 kW) @ 12, 000 rpm
Torque	80 Nm @ 9, 500 rpm
Fuel Capacity	17.4 litres (4.6 US gal)
Dry Weight	166 kg
Wet Weight	189 kg
Front Suspension	Showa 41 mm upside down
Rear Suspension	Ohlins STX40 piggyback reservoir monoshock, adjustable compression and rebound damping and preload adjustment
Front Brakes	Twin 310 mm floating discs, Brembo 4-piston radial monobloc calipers
Rear Brakes	Single 220 mm disc, Brembo single piston caliper
Frame	Aluminium beam twin spar
